Описание

Характеристики

• Суич, тип: Fixed Port
• Общ брой портове: 10
• Основни портове, тип: 8x10/100/1000Base-T
• Power Over Ethernet (PoE): IEEE 802.3af PoE Standard, Ports 1~8 up to 15.4 W per port, PoE Power Budget: Max. 45 W
• Uplink портове: 2xSFP
• Свободни (10GB) слотове: No
• Управление: Multi-Language Web-based GUI, Simplified CLI, Telnet Server, TFTP Client, SNMP (Supports v1, v2, v3), SNMP Trap, System Log (Max. 500 log entries), IPv6 Neighbor Discovery, Configurable MDI/MDIX, BootP/DHCP Client, DHCP Auto Configuration, RMON v1, SNTP
• Stackable: No
• Fans: Fanless design
• Захранване: Internal Universal Power Supply: 100 - 240 VAC, 50/60 Hz
• Routing: Layer 2 Only
• Памет (Flash, RAM): -
• Капацитет за маршрутизиране/превключване, Gbps: 20 Gbps
• Пропускателна способност, Mpps: 14.9Mpps
• MAC адреси: 16000 MAC address table size
• VLAN (брой, стандарти): IEEE 802.1Q; VLAN Group: max. 256 static VLAN groups, max. 4094 VIDs; Management VLAN; Asymmetric VLAN; Auto Voice VLAN: max. 10 user defined OUI, max. 8 default OUI; Auto Surveillance VLAN
• QoS: 802.1p Quality of Service; 8 queues per port; Queue Handling - Strict, Weighted Round Robin (WRR); Bandwidth Control - Port-based (Ingress/Egress, min granularity 10/100/1000 is 15 Kbps); CoS based on: 802.1p Priority Queues, DSCP, ToS, IPv6, TCP/UDP port
• L2 мрежови стандарти: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3az, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X
• L3 мрежови стандарти: -
• IPv6 functionality: IPv6 Neighbor Discovery
• Сигурност: Port Security, Broadcast/Multicast/Unicast Storm Control, Static MAC, D-Link Safeguard Engine, DHCP Server Screening, Trusted Host, ARP Spoofing Prevention (Max. 64 entries), SSL (Supports v1/v2/v3; Supports IPv4/IPv6), Traffic Segmentation, IEEE 802.3x
• Размери (Ш, Д, В), mm: 280 x 180 x 44
• Опция за монтаж: Desktop/Rackmount
• Гаранция: 99 месеца
