Компоненти за инверториDunext Naikong 2 Optical 8 Electric Switch
NCS5010-8T2SC
Growatt SYN 50-XH-10
200,40 €
ХарактеристикиХ-ка 1: Input from grid: Max. AC input overcurrent protection - 63A, Max. continuous input current - 50A, AC output voltage(nominal) - 230V (180-270V - range), AC frequency (nominal) - 50Hz/60Hz (45-65Hz - range), Grid Disconnection Switchover Time: <500ms Х-ка 2: Input from inverter…
Пълно описание и характеристики ↓Поръчай с обаждане
Остави телефон. Ще уточним поръчката и доставката с теб.
Описание
Характеристики
- Х-ка 1: Input from grid: Max. AC input overcurrent protection - 63A, Max. continuous input current - 50A, AC output voltage(nominal) - 230V (180-270V - range), AC frequency (nominal) - 50Hz/60Hz (45-65Hz - range), Grid Disconnection Switchover Time: <500ms
- Х-ка 2: Input from inverter: Rated AC Power-6000W, Max. Continuous Input Current@230V-26.1A, Rated AC Power in Continuous Backup Operation-6000W, Max. Continuous Input Current in Backup Operation-26.1A, Peak AC Power/Current(<10s) in Backup Operation-6600W/28.7A
- Х-ка 3: Communication: RS485
- Х-ка 4: Manual control bypass switch
- Х-ка 5: Cooling: Natural convection, Noise: <30dB
- Х-ка 6: Operating temperature range: –40 °C~60 °C, Operating humidity(rh): Up to 100%, Maximum elevation: 3000m
- Х-ка 7: IP65 Protection rating
- Х-ка 8: Dimensions(W/H/D): 365/450/123 mm, Weight: 11 kg
- Гаранция: 12 месеца
Още от колекцията
Компоненти за инвертори157,56 €
Компоненти за инверториHuawei Battery module LUNA2000-5-E1
1000000776
Компоненти за инверториDunext Max Current 1000AC85mV/ per 1000A@50Hz
ESCT-RC100-1000A
Компоненти за инвертори148,67 €
Характеристики
| Гаранция | 12 месеца |
|---|---|
| Х-ка 1 | Input from grid: Max. AC input overcurrent protection - 63A, Max. continuous input current - 50A, AC output voltage(nominal) - 230V (180-270V - range), AC frequ |
| Х-ка 2 | Input from inverter: Rated AC Power-6000W, Max. Continuous Input Current@230V-26.1A, Rated AC Power in Continuous Backup Operation-6000W, Max. Continuous Input |
| Х-ка 3 | Communication: RS485 |
| Х-ка 4 | Manual control bypass switch |
| Х-ка 5 | Cooling: Natural convection, Noise: <30dB |
| Х-ка 6 | Operating temperature range: –40 °C~60 °C, Operating humidity(rh): Up to 100%, Maximum elevation: 3000m |
| Х-ка 7 | IP65 Protection rating |
| Х-ка 8 | Dimensions(W/H/D): 365/450/123 mm, Weight: 11 kg |
